UVC System Dulcodes LP-D, 2 X 350 Watt

UVC System Dulcodes LP-D, 2 X 350 Watt

Loading...
In stock

The UVC Dulcodes is a world first in the field of chemistry-free disinfection of drinking water. This lamp is certified, which proves a guaranteed operation of the lamp.

The Dulcodes LP-D is the first UV installation that can be precisely adjusted over a wide temperature range and that has been specially designed for the disinfection of water Whiteh a low turbidity (= low transmission).

The unique combination of electronic ballast technology and the Vario-Flux lamps makes it possible to quickly and accurately dim the installation Whitehin a large capacity range of up to 50%. This automatically adjusts to the changing flow rates or changes in the water temperature. At the same time, the pressure loss is kept to a minimum.

Technical characteristics:

  • Hydraulically optimized reactor made of high-quality stainless steel 316L.
  • "Vario-Flux" amalgam lamps Whiteh high power and dynamic lamp heating.
  • Guaranteed lamp life 14000 hours (in proportion).
  • Electronic ballasts for economical ignition, operational monitoring, individual monitoring and control of the lamps.
  • DVGW / ÖVGW UVC sensor 160 ° opening angle, highly selective and aging stable, built into the measuring window.
  • Efficient and chemical-free cleaning of the quartz tubes Whiteh manual or automatic wiper system optionally available for selected installation sizes
  • Permanent monitoring of the reactor temperature thanks to temperature sensor Pt 1000.
  • Installation Whiteh 2 lamps.
  • Various options for easy integration of the installation in higher-level control technology thanks to numerous analog and digital interfaces and connections.
  • Data loggers: all relevant company data as well as results are stored on the SD card and can be visualized easily and comfortably Whiteh an analysis program.
  • The DULCOnnect module enables easy online monitoring and control of the installation via web-based access via LAN / WLAN interface. The current installation status can be displayed on an end device at any time.

Technical data:

  • Maximum flow rate: 35 m³/hour*
  • Radiator power: 835 Watt.
  • Minimum space for maintenance work: 1064 mm
  • Diameter: DN65

Your benefits:

  • Unique dynamic lamp heating adjusts the lamp capacity Whitehin a few seconds and ensures optimum disinfection, even Whiteh changing flow rates and water temperatures.
  • Homogeneous UV dose thanks to optimized flow dynamics in the reactor guarantees maximum flow Whiteh a minimum number of lamps and minimum pressure loss.
  • Reduction of the life cycle costs: Use of Vario-Flux lamps Whiteh high power Whiteh a long service life, low energy consumption and high UV yield
  • High flexibility: upright or horizontal installation and free choice of flange position
  • Control cabinet Whiteh efficient forced cooling ensures a long service life of the electronic components and protects against corrosion in aggressive environmental conditions
  • User-friendly and intuitive: The control for displaying operating states and setting operating parameters
