IF Dosing pump Beta5 0420 PVB2 (Medication)

The Beta5 0420 dosing pump is a universel magnet dosing pump for dosing fluid products in water treatment. It is a simple, robust membrane dosing pump. The mainly resistant magnet drive also guarantees a maximum lifespan in combination Whiteh a maximum duty.

Dosing pump Beta5's characteristics:

• Maximum pressure: 4bar
• Maximum dosing: 20 liter/hour.
• Maximum amount of beats/minute: 180
• Dosing amount: 1.85 mL/beat.
• Pump head made of PVDF (teflon).
• External control by potential free contacts Whiteh pulse multiplication and pulse division for the adaptation to the present signaler of 64:1 to 1:64.
• Beat frequentions-setting in steps of 10 %, 10 – 100 % resembles 18 – 180 beats/min
• Stepless beat length-setting of 0 - 100 % (recommended 30 - 100 %).
• Maximum height of suction: 3 m.
• Connections: 12 * 9 mm.

Please read the manual carefully before pump usage. Good maintenance encourages performance of IF Dosing pump Beta's ease of use. You can find the guidelines concerning usage, storage and transport in the safety information document.
